| Image Sensor |
1/3” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Aperture |
4 mm: F1.6 |
| Lens |
Fixed focal lens (4 mm) |
| Lens Mount |
M12 |
| Minimum Illumination |
0 lux with IR/white Light |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Unified/ Scheduled/ Auto |
| Digital Noise Reduction |
3D DNR |
| WDR |
DWDR |
| Weatherproof Rating |
IP66 |
| IR Working Distance |
30m |
| Pan/Tilt Range |
Pan: 0° to 350°, Tilt: 0° to 120° |
| Illumination Distance |
30 m |
| Viewing Angle |
(4mm) Horizontal FOV: 79° Vertical FOV: 43° Diagonal FOV: 93° |
| Digital Zoom |
Yes |
| Lens Type |
Fixed Focal Lens |
| Lens Focal Length |
4 mm |
| Lens Aperture |
F1.6 |
| Lens FOV |
Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° |
| DORI Distance |
Detect: 80 m (262 ft), Observe: 33 m (109 ft), Recognize: 16 m (52 ft), Identify: 8 m (26 ft) |
| PTZ Pan/Tilt Range |
Pan: 0° to 350°, Tilt: 0° to 120° |
| PTZ Pan Speed |
Configurable from 1° to 55°/s; Preset Speed: 55°/s |
| PTZ Tilt Speed |
Configurable from 1° to 40°/s, Preset Speed 40°/s |
| Manual Control Speed |
Configurable from 8° to 35°/s |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 8 presets for each patrol |
| Power-off Memory |
Yes; Auto restore to previous PTZ and lens status after power failure |
| Park Action |
Yes; Preset; Patrol Scan |
| 3D Positioning |
Yes |
| Angle Adjustment (Manual) |
Pan: 0° to 348°, Tilt: 0° to 120° |
| IR LED |
Quantity: 2, Range: 30m, Wavelength: 850nm |
| White LED |
Quantity: 2, Range: 30m |
| Illuminator Control |
Auto/Scheduled/Always on/Always off |
| Max Resolution |
2560 X 1440 |
| Main Stream Frame Rate |
50Hz: 1,5,10,15,20,25fps; 60Hz: 1,5,10,15,20,25,30fps |
| Main Stream Resolution |
2560x1440, 2304x1296, 2048x1280, 1920x1080 |
| Sub-Stream Frame Rate |
50Hz: 1,5,10,15,20,25fps; 60Hz: 1,5,10,15,20,25,30fps |
| Sub-Stream Resolution |
640x480, 352x288, 320x240 |
| Bit Rate Control |
CBR, VBR |
| Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.264+ |
Main Stream Supported |
| H.265 Type |
Main Profile |
| H.265+ |
Main Stream Supported |
| Video Bit Rate |
Main Stream: 256 Kbps to 4 Mbps; Sub-Stream: 64 Kbps to 512 Kbps |
| Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
| Image Enhancement |
BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range |
DWDR |
| SNR |
≥ 52 dB |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| OSD Setting |
Yes |
| Audio Communication |
Two-Way Audio |
| Audio Input |
Yes |
| Audio Output |
Yes |
| Audio Compression |
Yes |
| Audio Sampling Rate |
8KHz |
| Environment Noise Filtering |
Yes |
| Audio Bit Rate |
64 Kbps (G.711 alaw) |
| Network Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Wireless Rate |
11 Mbps (802.11b), 54 Mbps (802.11g), 150 Mbps (802.11n) |
| Wireless Security |
WPA/WPA2-PSK |
| ONVIF |
Yes |
| API |
ONVIF |
| Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
| Web Browser |
Chrome® 57+, Firefox® 52+, Safari® 11+, Edge 91+ |
| Cloud |
Yes |
| Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Wireless Standards |
IEEE 802.11b/g/n |
| WiFi Channels |
UN: 1-13, US: 1-11 |
| Frequency |
2.4 GHz |
| Wireless Transmit Power |
High |
| Auto Wireless Channel |
N/A |
| Wireless Statistics |
N/A |
| Throughput Monitoring |
N/A |
| Radio Bandwidth |
Auto: N/A, 20M: Yes, 40M: Yes |
| Wireless Mode |
AP, AP Client |
| Smart Event |
Area Intrusion Detection, Line-Crossing Detection, People Detection |
| Basic Event |
Motion Detection, Video Tampering Detection, Exception (Illegal Login) |
| Alarm Linkage |
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
| Linkage Method |
N/A |
| Output Notification |
Message Push |
| Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Audio Input |
Built-in Microphone |
| Audio Output |
Built-in Speaker |
| Alarm |
N/A |
| Reset Button |
Yes |
| Power |
DC Power Port |
| On-board Storage |
Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB |
| Built-in Microphone |
Yes; Records Anything Going on within a 16.4-ft (5 m) Radius |
| Built-in Speaker |
Yes |
| Operating Temperature |
-30–60 °C |
| Storage Temperature |
-40–60 °C |
| Operating Humidity |
95% or Less (Non-Condensing) |
| Storage Humidity |
95% or Less (Non-Condensing) |
| Package Content |
VIGI Network Camera, Quick Start Guide, Waterproof Cable Attachments, Power Adapter, Mounting Accessories |
| Dimensions (H×W×D) |
120 × 172 × 198 mm |
| Material |
Plastic |
| General Features |
Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Net Weight |
0.62 Kg |
| Gross Weight |
1.21 Kg |
| Max Power Consumption |
12V DC: Max 15.5W |
| Power Supply |
12V DC ± 5%, 5.5mm Coaxial Power Plug |
| Antenna |
Quantity: 2, Type: 2.4GHz Welded Dipole Omni-Directional, Gain: 2.0dBi |
| Protection |
IP66 |
| Certifications |
CE, RCM, BSMI, VCCI, RoHS, NCC, JRF, KC |
| Video/Stream Compression |
Main stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264 |
| Main Stream Frame Rate & Resolution |
1,5,10,15,20,25,30fps; 2560x1440, 2304x1296, 2048x1280, 1920x1080 |
| Sub-Stream Frame Rate & Resolution |
1,5,10,15,20,25,30fps; 640x480, 352x288, 320x240 |
| Video Streaming |
Main Stream, Sub-Stream |
| Image Enhancement |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, BLC/3D DNR/Prevent Overexposure to IR Light |
| Video Bit Rate |
Main Stream: 256 Kbps to 4 Mbps; Sub-Stream: 64 Kbps to 512 Kbps |
| Smart Feature-Set |
Smart Event: Area Intrusion Detection, Line-Crossing Detection, Human Detection; Basic Event: Motion Detection, Camera Tampering Detection, Exception (illegal login); Linkage Method: Trigger Notification: ONVIF, HTTPS; Region of Interest: 1 Region |
